EA-ELR 10360-30 2U Programmable Electronic DC Load with Energy Recovery

The EA-ELR 10360-30 2U is a high-performance programmable DC load and electronic DC load that features advanced energy recovery technology, feeding up to 94.5% of absorbed power back into the grid; as a 3000W DC load, it covers a wide voltage range of 0-360V and current range of 0-30A, with rapid dynamic response (10ms rise and fall times) and exceptional accuracy (0.05% voltage, 0.1% current, 0.3% power), supporting constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR) operating modes, and integrates a built-in function generator, battery test function, and MPP tracking for solar panel testing, plus multiple interfaces including USB, Ethernet, analog, and optional digital modules for flexible remote control, and enables parallel operation with up to 64 units via master-slave bus for scalable high-power applications, making it an ideal solution for testing power supplies, programmable DC power sources, and other DC sources with high efficiency and precision.

Key Features

• Energy Recovery Efficiency: Recuperates up to 94.5% of energy back to the AC grid, reducing operating costs and thermal load.
• High Power and Range: Delivers 3000W power with 0-360V voltage and 0-30A current for broad testing capabilities.
• Fast Dynamic Performance: 10ms rise and fall times enable quick transient response for dynamic load testing.
• High Precision Measurement: Offers 0.05% voltage accuracy, 0.1% current accuracy, and 0.3% power accuracy for reliable results.
• Multiple Operating Modes: Supports CV, CC, CP, and CR modes for versatile load simulation.
• Advanced Testing Functions: Includes built-in function generator, battery test, and MPP tracking for comprehensive applications.
• Extensive Connectivity: Features USB, Ethernet, analog interfaces, and optional digital modules (e.g., CAN, Profibus) for seamless integration.
• Scalable System Design: Allows parallel operation of up to 64 units for higher power requirements.
• User-Friendly Operation: Equipped with a 5-inch color TFT touchscreen and intuitive controls for easy setup and monitoring.
• Robust Construction: 19-inch 2U rack-mount design with forced air cooling ensures durability in industrial environments.
