EA-PUL 10360-480 6U WC Programmable Regenerative DC Electronic Load

The EA-PUL 10360-480 6U WC is a high-power, 60 kW programmable electronic DC load unit with integrated energy recovery, offered in a water-cooled (WC) configuration. As part of the EA-PUL 10000 series, it operates as a bidirectional DC load, consuming DC power from a device under test (DUT) and regenerating it back into the AC grid with exceptional efficiency up to 95.8%. This significantly reduces operational costs and heat dissipation compared to traditional resistive loads. It features a wide autoranging DC input capable of 0 - 360 V and 0 - 480 A, delivering a full 60 kW across a broad operating range (0.025 Ω - 45 Ω). The unit accepts a three-phase AC input (380 V - 480 V ±10%) with active Power Factor Correction (typical 0.99). Designed for scalability, it includes a galvanically isolated Master-Slave bus and Share-Bus for seamless parallel operation of up to 64 units, enabling systems up to 3840 kW. It is equipped with standard interfaces (USB, Ethernet, Analog) and supports numerous optional industrial communication protocols (CANopen, Modbus, Profinet, EtherCAT, etc.). The integrated water cooling option ensures efficient thermal management in high-density or noise-sensitive installations. This load is ideal for demanding applications such as high-power battery testing, fuel cell characterization, on-board charger (OBC) validation, and battery recycling processes.

Key Features

• Regenerative & Highly Efficient: Feeds absorbed DC energy back into the AC grid with up to 95.8% efficiency, slashing energy costs and cooling requirements.
• Wide Autoranging DC Input: Provides flexible operation with 0 - 360 V, 0 - 480 A, and 0 - 60 kW constant power capability, replacing multiple single-range loads.
• Multiple Regulation Modes: Offers precise control in Constant Voltage (CV), Constant Current (CC), Constant Power (CP), and Constant Resistance (CR) modes with fast crossover.
• Master-Slave & Share-Bus for Scalability: Enables easy parallel connection of up to 64 units (mixed power classes, same voltage class) to behave as a single, high-power system (up to 3840 kW).
• Comprehensive Interfaces: Comes with built-in galvanically isolated USB, Ethernet (100 MBit), and analog (DB15) interfaces. Optional slots support CAN, CANopen, RS232, Profibus, EtherCAT, Profinet, and Modbus.
• Water Cooling Option (WC): Stainless steel water cooling system for superior heat dissipation, ideal for maximizing power density and minimizing acoustic noise.
• High Performance AC Input: Wide three-phase input range (380-480 VAC), active PFC (~0.99), and low leakage current ensure compatibility with global grids and clean power draw.
• Robust Safety & Protection: Includes adjustable OVP, OCP, OPP, and overtemperature protection. Meets key safety (EN/IEC/UL 61010-1) and EMC standards.
