EA-PU 10500-360 6U WC Programmable DC Power Supply 60 kW

The EA-PU 10500-360 6U WC is a high-performance, 60 kW programmable DC power supply and bidirectional DC source designed for demanding industrial and laboratory applications. Featuring a wide autoranging output of 0-500V and 0-360A, it maintains a constant 60 kW power curve, offering exceptional flexibility. With an efficiency of up to 96.5% and active Power Factor Correction (typical 0.99), it ensures energy-efficient operation from a 380-480V ±10%, 3-phase AC input. This water-cooled (WC) version provides robust thermal management for continuous high-power operation. Equipped with a Master-Slave Bus and Share-Bus for seamless parallel operation of up to 64 units, it can scale to systems up to 3.84 MW. It supports multiple control modes (CV, CC, CP, CR), includes comprehensive digital and analog interfaces, and is ideal for applications such as fuel cell simulation, electrolysis power supplies, electric vehicle component testing, and solar array simulation.

Key Features

• High Power & Autoranging Output: Delivers 60 kW constant power with a wide programmable range of 0-500V and 0-360A, functioning as a versatile programmable DC source.
• Superior Efficiency & Input Specifications: Achieves up to 96.5% efficiency with active PFC (~0.99) from a 380-480V, 3-phase AC input, reducing operational costs and grid impact.
• Robust Water-Cooled Design: The WC (Water Cooling) option ensures reliable thermal performance for sustained high-power output in a compact 6U, 82 kg chassis.
• Scalable System Architecture: Integrated Master-Slave and Share-Bus enables parallel operation of up to 64 units, creating systems up to 3840 kW that behave as a single DC power system.
• Advanced Control & Interfaces: Offers CV, CC, CP, CR modes with fast crossover, 16-bit resolution, and built-in USB, Ethernet, and analog interfaces. Optional industrial protocols (CANopen, Profinet, Modbus, etc.) are available.
• Application-Oriented: Perfectly suited as a fuel cell simulator, electrolysis power supply, test source for EV components, solar inverter tester, or in automated production test systems.
