EA-PUL 11000-160 6U Programmable Electronic DC Load with Energy Recovery

The EA-PUL 11000-160 6U is a high-performance, bidirectional DC load system featuring advanced energy recovery technology. As part of the EA-PUL 10000 series, this 60 kW unit is designed for demanding applications such as testing high-power programmable DC power supplies, computer power supplies, battery systems, fuel cells, and on-board chargers (OBC). It operates as a regenerative electronic load, feeding up to 96% of the absorbed DC power back into the AC grid, dramatically reducing energy costs and heat dissipation. With a wide autoranging DC input of 0-1000 V and 0-160 A, it offers exceptional flexibility. The unit supports CV, CC, CP, and CR regulation modes with fast crossover and high accuracy. Equipped with a Master-Slave bus and Share-Bus, up to 64 units can be paralleled to create systems up to 3840 kW, behaving as a single, cohesive system.

Key Features

• Regenerative & Efficient: Recovers energy to the grid with up to 95.8% efficiency, reducing operating costs and cooling requirements.
• High Power & Autoranging: Delivers 60 kW within a wide 0-1000 V / 0-160 A range, eliminating the need for multiple fixed-range loads.
• Programmable & Precise: Offers CV, CC, CP, CR modes with digital regulation (16-bit ADC/DAC), high stability (CV ≤0.05% FS), and measurement accuracy (Voltage ≤0.05% FS, Current ≤0.1% FS).
• Scalable System: Integrated Master-Slave and Share-Bus enables seamless parallel operation of up to 64 units for multi-megawatt systems.
• Comprehensive Interfaces: Built-in USB, Ethernet, and isolated analog (DB15). Optional CAN, CANopen, Modbus, Profinet, EtherCAT, etc., for easy integration.
• Robust & Safe: Complies with IEC/UL 61010-1 safety standards. Features OVP, OCP, OPP, and OT protection. IP20 rating and pollution degree 2.
• Application Ready: Ideal for battery pack/module testing (SOH, EOL), fuel cell test, on-board charger (OBC) test, and power supply aging tests.
