EA-PUL 10750-240 6U 60000W Programmable Electronic DC Load with Energy Recovery

The EA-PUL 10750-240 6U is a high-performance, regenerative programmable electronic DC load unit capable of handling up to 60000W. It functions as a programmable DC load, a benchtop power supply tester, and a programmable DC power source for demanding applications. As part of the PUL 10000 series, it features advanced energy recovery technology, feeding up to 96.5% of consumed DC energy back into the AC grid with high efficiency. It offers a wide autoranging DC input of 0-750V and 0-240A, providing exceptional flexibility. With its programmable capabilities, support for CV, CC, CP, and CR regulation modes, and built-in interfaces (USB, Ethernet, Analog), it is ideal for computer power supply testing, battery test systems, fuel cell test systems, on-board charger test, and battery recycling systems. The unit supports parallel operation of up to 64 devices via its Master-Slave and Share-Bus, enabling the creation of high-power systems up to 3840 kW for cell test, module test, pack test, State of Health (SOH) test, and End of Line (EOL) test applications.

Key Features

• Regenerative Energy Recovery: Feeds consumed DC energy back into the AC grid with an efficiency of up to 96.5%, reducing operating costs and heat generation.
• High Power & Wide Autoranging Input: Delivers 60000W with a flexible DC input range of 0-750V and 0-240A, maximizing application versatility.
• Multiple Regulation Modes: Supports Constant Voltage (CV), Constant Current (CC), Constant Power (CP), and Constant Resistance (CR) modes with fast crossover for precise control.
• Scalable System Architecture: Equipped with galvanically isolated Master-Slave and Share-Bus for parallel operation of up to 64 units, behaving as a single, high-power system.
• Comprehensive Interfaces: Includes built-in USB, Ethernet, and Analog (DB15) interfaces. Optional industrial interfaces include CAN, CANopen, Modbus, Profinet, and EtherCAT.
• Application-Optimized: Specifically designed for battery testing (cell/module/pack, SOH, EOL), fuel cell test, on-board charger test, and battery recycling, providing accurate and reproducible results.
• Advanced Control & Software: Programmable via SCPI, ModBus, and compatible with LabVIEW and IVI drivers. Includes EA Power Control software for sequencing and data logging.
