TPS030-DR12Pro 30W Din Rail Power Supply

The TPS030-DR12Pro is a high-performance ac to dc power supply and din rail power supply from the TPS DR+ Series, also serving as a reliable 12v power supply, 12v dc power supply, 12 volt power supply, 12 dc power supply, and 30W power supply for industrial and commercial applications. As a professional TPS power supply, this TPS030 12V model supports a wide automatic input range of 90-264VAC 47-63Hz or 120-370VDC, with a power factor >0.96 for optimized grid compatibility. It delivers stable 12V DC output with a 12V to 15V adjustable range, 2.5A rated output current, 30W continuous output power, and up to 93% conversion efficiency at full load and 220VAC input. This dc power supplies unit features <1% output voltage ripple and noise, 20ms hold-up time at full load and 230VAC input, and comprehensive auto-recover protections including over temperature protection (OTP), over voltage protection (OVP), and overload protection. It adopts convection cooling design, is compatible with standard DIN RAIL TS 35/7.5 or TS 35/15 vertical mounting, accepts cable in AWG26-14 (0.15 - 2.5 mm²) for N, L and DC terminals, and operates in 0°C - 70°C ambient temperature with derating from 50°C to 70°C. This TPS030 30W power supply is CE, UL and TUV certified, complies with UL60950-1, UL508, EN60950-1 standards, Low-Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU, and comes with a 5-year manufacturer warranty. It is a reliable alternative for meanwell power supply models in the same power class, and the TPS DR+ Series also covers diverse power needs including 24v power supply, 24vdc power supply, 24 volt power supply, power supply for 12v, power supply for 12 volt, and 5v power supply applications. Ideal for automation industry, LED lighting, telecommunication systems, industrial control, and building automation projects.

Key Features

• Wide Automatic Input Range: Supports 90-264VAC 47-63Hz or 120-370VDC input with >0.96 high power factor for global grid compatibility.
• Adjustable Stable DC Output: Provides 12V DC output with 12V to 15V adjustable range, 2.5A rated output current, and 30W continuous power for flexible application matching.
• Ultra-High Efficiency: Delivers up to 93% full load conversion efficiency to minimize energy loss and reduce operating costs.
• Clean & Stable Power Output: Features less than 1% output voltage ripple and noise, plus 20ms hold-up time at full load for sensitive equipment compatibility.
• Comprehensive Auto-Recover Protections: Equipped with OTP, OVP, and overload protection to ensure long-term reliable operation in harsh industrial environments.
• Noiseless Convection Cooling: Adopts convection cooling design without fan, ensuring silent operation and long service life.
• Safety & Global Certifications: CE, UL and TUV certified, complies with UL60950-1, UL508, EN60950-1, and EU LVD/EMC directives.
• Convenient Din Rail Mounting: Compact design compatible with standard DIN RAIL TS 35/7.5 or TS 35/15 vertical mounting for quick installation.
• Long-Term Reliability: Backed by a 5-year manufacturer warranty, with >350,000 hours demonstrated MTBF at full load and 25°C ambient.
• Wide Application Compatibility: Optimized for automation industry, LED lighting, telecommunication systems, and industrial control projects.
