EA-PUL 11000-160 6U WC Programmable Electronic DC Load with Energy Recovery

The EA-PUL 11000-160 6U WC is a high-performance, water-cooled, programmable electronic DC load unit featuring bidirectional operation and regenerative energy recovery. Capable of handling up to 60 kW of power, it offers a wide DC input range of 0-1000 V and 0-160 A, making it an ideal solution for testing high-voltage components, power supplies, and energy systems. Its standout feature is the active energy recovery system, which feeds up to 96.5% of the consumed DC energy back into the AC grid with high efficiency, significantly reducing operational costs and heat dissipation. The unit operates with a flexible autoranging constant power characteristic, allowing full 60 kW power delivery across a broad voltage and current spectrum. It supports multiple regulation modes including constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR) with fast crossover. Designed for scalability, it includes a galvanically isolated Master-Slave bus and Share-Bus for seamless parallel operation of up to 64 units, enabling system power expansion up to 3840 kW. Standard interfaces include USB, Ethernet, and an isolated analog DB15 port, with optional industrial communication modules (CAN, CANopen, Profibus, EtherCAT, Profinet, Modbus) available. Compliant with major safety and EMC standards (EN/IEC/UL 61010-1, EN 55011 Class A), it is built in a robust 6U 19-inch rack enclosure with IP20 protection and is equipped for forced air or optional water cooling (WC version). Primary applications include battery testing for electro-mobility (cell, module, pack, SOH, EOL), fuel cell testing, on-board charger (OBC) validation, battery recycling, and testing of photovoltaic inverters and electric vehicle powertrains.

Key Features

• High Power & Voltage Range: Delivers 60 kW within a 0-1000 V, 0-160 A DC input range, suitable for high-voltage component testing.
• Regenerative Energy Recovery: Feeds consumed energy back into the AC grid with up to 96.5% efficiency, lowering energy costs and cooling requirements.
• Water-Cooled Design (WC): Enhanced thermal management via integrated water cooling for sustained high-power operation.
• Autoranging & Constant Power: Flexible input stage maintains full 60 kW power across wide voltage and current ranges (autoranging).
• Multiple Regulation Modes: Offers CV, CC, CP, and CR modes with fast crossover and digital control (16-bit ADC/DAC).
• Scalable Parallel Operation: Master-Slave and Share-Bus allow parallel connection of up to 64 units as a single system (up to 3840 kW).
• Comprehensive Interfaces: Standard USB, Ethernet, analog I/O; optional CAN, CANopen, Profibus, EtherCAT, Profinet, Modbus.
• Precise Measurement: High accuracy with voltage measurement ≤0.05% FS and current measurement ≤0.1% FS.
• Robust Safety & Compliance: Meets EN/IEC/UL 61010-1, EN 55011 Class A, with OVP, OCP, OPP, and OT protection.
• Application-Optimized: Ideal for battery test systems, fuel cell testing, on-board charger test, EV powertrain test, and PV inverter test.
