EA-PUB 11000-160 6U WC Programmable Bidirectional DC Power Unit

The EA-PUB 11000-160 6U WC is a high-performance, water-cooled, programmable bidirectional DC power supply unit capable of delivering up to 60 kW. It functions both as a precise power source (source) and a regenerative electronic load (sink), recovering up to 96.5% of energy back to the AC grid with high efficiency. Designed for demanding industrial and laboratory applications, it features a wide output range of 0-1000 V and 0-160 A with auto-ranging (constant power) characteristics. With three-phase AC input (380-480 V ±10%), active Power Factor Correction (PFC ~0.99), and comprehensive digital interfaces, it is ideal for battery testing, fuel cell test systems, PV inverter testing, on-board charger validation, and battery simulation/recycling.

Key Features

• Bidirectional & Regenerative Operation: Acts as both a DC power supply and an electronic load, feeding recovered energy back into the grid with efficiency up to 96.5%.
• High Power & Wide Auto-Ranging Output: Delivers 60 kW with a flexible output range of 0-1000 V and 0-160 A, providing broad application coverage in a single unit.
• Water-Cooled Design (WC Option): Enhanced cooling solution for sustained high-power operation, reducing thermal noise and enabling high-density system integration.
• Active Power Factor Correction: Features near-unity power factor (~0.99), minimizing harmonic distortion and reducing input current requirements.
• Advanced Parallel Operation: Integrated Master-Slave and Share-Bus allow seamless parallel connection of up to 64 units for systems up to 3840 kW.
• Multiple Control & Interface Options: Supports CV, CC, CP, CR modes; includes USB, Ethernet, isolated analog I/O; offers optional CAN, CANopen, Profinet, EtherCAT, Modbus, etc.
• High Precision & Fast Dynamics: 16-bit digital control, ≤0.05% voltage accuracy, ≤0.1% current accuracy, and fast transient response (CV rise/fall ≤10 ms).
• Comprehensive Safety Protections: Includes adjustable OVP, OCP, OPP, and overtemperature protection for reliable operation.
• Application-Oriented Software: Compatible with EA Power Control and EA Battery Simulator software for automated testing and simulation.
