EA-ELR 10080-510 3U Programmable Electronic DC Load with Energy Recovery

The EA-ELR 10080-510 3U is a high-power, programmable electronic DC load designed for demanding industrial and laboratory testing applications. Part of the advanced ELR 10000 Series, this model stands out with its exceptional current handling capability of 0-510A and a wide voltage range of 0-80V, enabling a maximum power dissipation of 15,000W. Its defining feature is the integrated energy recovery system, which converts up to 94.5% of the absorbed DC power and feeds it back into the local AC grid, dramatically reducing energy costs and heat generation. The load operates on a three-phase AC input (380-480V ±10%) for full performance, with an automatic derating to 9,000W when used on a 208V AC supply. It supports all standard operating modes—Constant Current (CC), Constant Voltage (CV), Constant Power (CP), and Constant Resistance (CR)—and is equipped with a sophisticated function generator for creating complex test sequences like sine, triangle, and arbitrary waves, including simulations per DIN 40839 for automotive testing. Dedicated functions for Battery Testing (static and dynamic discharge) and MPP Tracking for solar panel characterization make it incredibly versatile. With support for master-slave parallel operation of up to 64 units and a comprehensive suite of interfaces (USB, Ethernet, Analog, and optional plug-in modules for CAN, Profibus, etc.), the EA-ELR 10080-510 3U is an efficient and powerful solution for validating power supplies, testing batteries, performing component burn-in, and simulating real-world load conditions.

Key Features

• High Power & Current Capability: Delivers a massive 15,000W load capacity with a very high current range of 0-510A and a voltage range of 0-80V, ideal for testing high-current sources and large battery packs.
• Advanced Energy Recuperation: Features a regenerative design that recovers up to 94.5% of the consumed DC energy and feeds it back into the AC mains, significantly lowering operating costs and cooling requirements.
• Comprehensive Operating Modes: Offers Constant Current (CC), Constant Voltage (CV), Constant Power (CP), and Constant Resistance (CR) modes for flexible and precise testing of various DC sources and components.
• Integrated Function Generator: Includes a built-in arbitrary function generator to create complex current or voltage profiles, such as sine, triangle, rectangle, trapezoid, and user-defined sequences, plus DIN 40839 automotive simulation.
• Specialized Test Functions: Provides dedicated Battery Test functions for capacity and cycle testing, and MPP Tracking to simulate and analyze the performance of photovoltaic panels and find their maximum power point.
• Scalable Master-Slave System: Enables parallel connection of up to 64 identical or compatible units to create a single, high-power system with a unified interface and automatic current sharing.
• Extensive Connectivity: Supports local control via a color touchscreen and remote control via built-in USB, Ethernet, and Analog interfaces, with optional plug-in modules for CAN, Profibus, Profinet, ModBus TCP, and more.
• Robust Protection & Monitoring: Equipped with fully adjustable Over Voltage (OVP), Over Current (OCP), Over Power (OPP), and Over Temperature (OT) protections, along with user-definable events for safe and reliable operation.
