EA-PU 11000-160 6U 60000W Programmable DC Power Supply

The EA-PU 11000-160 6U 60000W is a high-performance programmable DC power supply and autoranging bench power supply that delivers 0-1000V and 0-160A with a constant power output of 60kW, achieving up to 95.8% efficiency; as a versatile programmable DC power source, it supports multiple regulation modes including Constant Voltage (CV), Constant Current (CC), Constant Power (CP), and Constant Resistance (CR) with fast crossover, utilizes 16-bit ADC and DAC for high-resolution digital control, offers built-in galvanically isolated interfaces such as USB, Ethernet, and analog (DB15), and optional industrial interfaces including CAN, CANopen, RS232, Profibus, EtherCAT, Profinet, and Modbus; it features active Power Factor Correction (typical 0.99), wide AC input range (380-480V, 3-phase, 45-65Hz), and can be paralleled with up to 64 units via Master-Slave and Share-Bus for systems up to 3840kW, making it an ideal top budget PSU for high-power applications like fuel cell simulation, electrolysis power supply, electric vehicle component testing, solar array simulation, and relay testing.

Key Features

• High Power & Autoranging Design: Delivers 60kW with 0-1000V voltage range and 0-160A current range, providing flexible autoranging output for wide application coverage.
• Multiple Regulation Modes: Supports CV, CC, CP, and CR modes with fast crossover, ensuring precise control for various testing scenarios.
• High Efficiency & Reliability: Achieves up to 95.8% efficiency with active PFC (typical 0.99), reducing energy consumption and operating costs.
• Advanced Programmability & Interfaces: Equipped with 16-bit digital control, built-in USB, Ethernet, analog, and optional industrial interfaces for easy integration and automation.
• Scalable Parallel Operation: Allows parallel connection of up to 64 units via Master-Slave and Share-Bus, enabling systems up to 3840kW and 64000A.
• Robust Protection & Safety: Includes OVP, OCP, OPP, OT protection, and complies with EN 61010-1, UL 61010-1, and EMC standards for safe operation.
• Application-Optimized: Ideal for high-power testing such as how can I test a power supply, fuel cell simulation, electrolysis, EV components, and solar inverter testing.
