EA‑PSI 9040‑60 DT | 40V 60A 1500W High Current Auto-Ranging Programmable Desktop DC Power Supply

The EA‑PSI 9040‑60 DT belongs to EA‑PSI 9000 DT series manufactured by EA Elektro‑Automatik and distributed by TPS. As high-current alternative to ametek/amtek bench power supplies, it’s widely used for high-current 24V power source testing, new energy & industrial DC power verification and lab development projects.

Core Specs: 0~40V / 0~60A continuously adjustable, rated 1500W max power, peak auto-ranging output, efficiency up to 92%. Ultra-low ripple (10mV PP /1.5mV RMS, I ripple 6mA RMS). 90~264V full-range active PFC AC input (derate to 1000W below 150VAC); 40V SELV compliant per EN60950, built-in output discharge circuit, full OVP/OCP/OPP/OTP multi-protection.

Key Features

• EA‑PSI 9040‑60 DT, 40V 60A 1500W high current lab DC supply, PN:06200516
• EA‑PSI 9000 DT desktop chassis:308×103×415mm, approx.8.2kg weight
• Active PFC 90‑264V universal AC, auto-ranging CV/CC/CP/CR four regulation modes
• Built-in multi-function generator: Sine/Triangle/Rect/Trapezoid/Ramp/DIN40839/Arbitrary waveform
• Constant internal resistance simulation for battery & electronic load simulation test
• Full safety protection + front remote sensing to compensate cable voltage drop
• Galvanic isolated 15Pin Analog + USB-A/USB-B + Ethernet standard onboard ports
• SCPI/ModBus RTU compliant, EA Power Control & LabView driver supported
• Front USB for test waveform/user profile save/load, foldable tilt stand design
