EA‑ELR 10200‑50 2U | 200V 50A 3000W Energy‑Recuperating 19" 2U Rack‑Mount Programmable DC Electronic Load

The EA‑ELR 10200‑50 2U belongs to EA‑ELR 10000 2U series from EA Elektro‑Automatik, distributed by TPS. It is a high‑power regenerative DC electronic load as alternative to ametek/amtek test instruments. Suitable for power supply aging test, high‑voltage battery discharge test, 24V DC source validation, PV module evaluation and industrial prototype ATE test systems.

Core Specifications: DC input 0‑200V, 0‑50A, rated 3000W (derates to 1500W under 110‑127V AC mains), max energy‑recovery efficiency up to 94.5%. Minimum input voltage for full‑scale current:2V. CC‑mode rise / fall time ≤10 ms; measurement accuracy: voltage ≤0.05% FS, current ≤0.1% FS, power ≤0.3% FS. Supports CV / CC / CP / CR four regulation modes, resistance adjustment range:0.1 Ω‑250 Ω. Wide‑range 100‑264V AC input, integrated multi‑function generator, battery‑test and MPP‑tracking function. Compact 19‑inch 2U rack‑mount chassis with front‑to‑rear temperature‑controlled forced air cooling.

Key Features

• EA‑ELR 10200‑50 2U, 200V 50A 3000W regenerative programmable DC electronic load, PN:33200846
• 19‑inch 2U rack‑mount enclosure, dimension 482.6×88.4×559mm, weight approx.12.7kg
• High‑efficiency energy recuperation, returns absorbed DC power back to AC grid, reduces heat output and long‑run operating costs
• CV / CC / CP / CR four operating modes, constant‑resistance simulation for battery characteristic test scenarios
• 5‑inch capacitive TFT touch‑screen, dual push‑rotary knobs; front‑panel USB‑Host for CSV logging, waveform and user‑profile import‑export
• Built‑in multi‑function generator: Sine, Triangle, Rectangle, Trapezoid, DIN40839, Arbitrary, Ramp, XY‑table; dedicated battery discharge test & MPPT solar panel simulation
• Comprehensive alarm protection: OVP, OCP, OPP, OT, Power‑Fail, Share‑Bus‑Fail with automatic DC‑input shutdown
• Remote‑sense terminals for DC cable IR‑drop compensation; galvanically‑isolated 15‑pin analog, rear USB & Ethernet onboard control interfaces
• Master‑Slave / Share‑Bus parallel expansion, supports up to 64 units to construct high‑power combined test system
• SCPI / ModBus RTU protocol compliant, EA Power Control software and LabView driver available; optional IF‑AB plug‑in modules: CANopen, ProfiNet, EtherCAT, RS232, ModBus‑TCP etc.
• Complies with EN 61010‑1 safety standard, IP20 ingress protection for laboratory and industrial test environments
