EA‑ELR 10080‑60 2U | 80V 60A 1500W Energy‑Recovering 19" 2U Rack‑Mount Programmable DC Electronic Load

The EA‑ELR 10080‑60 2U belongs to EA‑ELR 10000 2U series manufactured by EA Elektro‑Automatik and distributed by TPS. It serves as regenerative DC electronic load alternative to ametek/amtek test instruments. Widely used for 80V battery discharge test, DC power supply ageing validation, 24V source testing, medium‑volume production test and laboratory ATE system development.

Core Specifications: DC input range 0‑80V, 0‑60A, rated 1500W (derates to 1200W under 110‑127V AC mains), maximum energy‑recovery efficiency up to 94%. CC‑mode rise / fall time ≤10 ms; measurement accuracy: voltage ≤0.05% FS, current ≤0.1% FS, power ≤0.3% FS. Supports CV / CC / CP / CR four regulation modes, built‑in multi‑function generator, battery test and MPP‑tracking function. Compact space‑saving 19‑inch 2U rack‑mount chassis with front‑to‑rear temperature‑controlled forced air cooling.

Key Features

• EA‑ELR 10080‑60 2U, 80V 60A 1500W regenerative programmable DC electronic load, PN:33200840
• 19‑inch 2U rack‑mount enclosure, dimension 482.6×88.4×559mm, weight approx.9.5kg
• Energy‑recuperation function feeds absorbed DC energy back to AC grid with up to 94% efficiency, reduces heat dissipation and operating cost
• CV / CC / CP / CR four operating modes, resistance adjustment range:0.04 Ω‑80 Ω, minimum operating U for full‑scale I max:0.8V
• 5‑inch capacitive TFT touch‑screen, dual push‑rotary knobs, front‑panel USB‑Host for CSV data logging, waveform & user profile import‑export
• Integrated multi‑function generator: Sine, Triangle, Rectangle, Trapezoid, DIN40839, Arbitrary, Ramp, XY‑table; dedicated battery test & MPPT solar panel simulation
• Comprehensive protection: OVP, OCP, OPP, OT, Power‑Fail, Share‑Bus‑Fail, auto DC‑input shutdown upon alarm trigger
• Remote‑sense terminals for DC cable IR‑drop compensation; galvanically‑isolated 15‑pin analog, rear USB & Ethernet onboard communication interfaces
• Master‑Slave / Share‑Bus parallel expansion support, connect up to 64 identical‑series units for high‑power combined test system
• SCPI / ModBus RTU protocol compliant, EA Power Control software and LabView driver available; optional IF‑AB interface modules: CANopen, ProfiNet, EtherCAT, RS232, ModBus‑TCP etc.
• Meets EN 61010‑1 safety standard, IP20 ingress protection for laboratory and industrial test environment
