EA‑ELR 10080‑120 2U | 80V 120A 3000W Energy‑Recovering 19" Rack‑Mount Programmable DC Electronic Load

The EA‑ELR 10080‑120 2U belongs to EA‑ELR 10000 2U series by EA Elektro‑Automatik, distributed by TPS. It is a regenerative DC electronic load alternative to ametek/amtek test equipment, widely deployed for battery discharge testing, power supply aging test, 24V DC source validation, fuel‑cell and PV panel characteristic evaluation in lab and industrial ATE systems.

Core Specifications: DC input 0‑80V, 0‑120A, rated 3000W (derates to 1500W under 110‑127V AC mains), max energy‑recovery efficiency up to 94%. Rise / fall time ≤10ms for CC mode; measurement accuracy: voltage ≤0.05% FS, current ≤0.1% FS, power ≤0.3% FS. Supports four regulation modes CV / CC / CP / CR, built‑in multi‑function generator, battery‑test and MPP‑tracking function. 19‑inch 2U rack design with forced front‑to‑rear air cooling.

Key Features

• EA‑ELR 10080‑120 2U, 80V 120A 3000W regenerative programmable DC electronic load, PN:33200845
• 19‑inch 2U rack‑mount chassis, dimension 482.6×88.4×559mm, weight approx.12.7kg
• Energy‑recovery function feeds absorbed DC power back to AC grid with up to 94% efficiency, saving cooling energy consumption
• CV / CC / CP / CR four operating modes, resistance range:0.02 Ω‑40 Ω
• 5‑inch capacitive TFT touch‑screen, dual rotary encoders, front‑panel USB‑Host for CSV logging / waveform/profile import‑export
• Integrated function generator: Sine, Triangle, Rectangle, Trapezoid, DIN40839, Arbitrary, Ramp, XY‑table; dedicated battery test & MPPT solar simulation
• Full‑range protection: OVP, OCP, OPP, OT, Power‑Fail, Share‑Bus fail alarm with DC‑input auto‑shutdown
• Remote‑sense terminals for cable IR‑drop compensation; galvanically‑isolated 15‑pin analog, rear USB & Ethernet onboard interfaces
• Support Master‑Slave / Share‑Bus parallel expansion, max up to 64 units for high‑power test system
• SCPI / ModBus RTU protocol compatible, EA Power Control software & LabView driver available; optional IF‑AB interface modules: CANopen, ProfiNet, EtherCAT, RS232 etc.
• Compliant with EN 61010‑1 safety standard, IP20 protection grade for laboratory & industrial test environment
