EA-PSI 9750-06 DT 1000W Programmable DC Power Supply

The EA-PSI 9750-06 DT is a high-performance, microprocessor-controlled laboratory and benchtop DC power supply designed for demanding applications. It delivers a wide output range of 0...750V and 0...6A, with a maximum power of 1000W. Featuring a flexible auto-ranging output stage, it intelligently adjusts voltage and current to maintain the set power limit. The unit boasts high efficiency up to 93% and incorporates an active Power Factor Correction (PFC) for operation on worldwide AC mains from 90...264V. Its built-in additional output filter ensures low ripple and noise on the DC output. Safety is paramount, with comprehensive protection features including Overvoltage (OVP), Overcurrent (OCP), Overpower (OPP), and Overtemperature (OT) protection. Models with 200V or higher nominal voltage include a discharge circuit that reduces the output to a safe level (<60V DC) within 10 seconds after shutdown.

Key Features

• High Voltage & Power: Provides 0...750V DC output at up to 6A, delivering up to 1000W of clean, programmable power for high-voltage testing needs.
• Intuitive Touch Panel: Features a color TFT touchscreen display for easy visualization of set/actual values, status, and intuitive control of all functions.
• Integrated Function Generator: Includes a true arbitrary function generator to apply complex voltage or current waveforms (sine, square, pulse, etc.) to the output, with support for up to 99 user-defined sequences.
• Comprehensive Connectivity: Comes standard with USB (Type B for control, Type A for storage), Ethernet, and a galvanically isolated analog interface (0-5V/0-10V) for seamless integration into automated test systems.
• Advanced Programmability: Supports SCPI command language and ModBus RTU for precise remote control and automation via software (including included EA Power Control software for Windows).
• Remote Sensing: Standard sense inputs compensate for voltage drops in load cables, ensuring accurate voltage is delivered directly at the device under test.
• Robust Protection & Safety: Equipped with configurable OVP, OCP, OPP, and OT protection, along with a discharge circuit for high-voltage models, ensuring safety for both the unit and the connected load.
• High Efficiency & Active PFC: Achieves up to 93% efficiency with active PFC, reducing energy consumption and compliant with global power quality standards.
