EA-ELR 12000-20 3U Programmable DC Electronic Load with Energy Recovery

The EA-ELR 12000-20 3U is a high-voltage, energy-recovering programmable DC electronic load designed for rigorous testing of power sources and components. With a maximum voltage of 2000V, current of 20A, and power handling up to 15000W (derated to 9000W at 208V AC input), this unit offers exceptional performance for demanding applications. It achieves up to 95.5% efficiency by feeding recovered energy back into the local grid, reducing operational costs. The load supports constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR) modes, with a resistance range from 3.5Ω to 5300Ω and an input capacitance of 60µF. Integrated protections include overvoltage (OVP), overcurrent (OCP), and overpower (OPP) safeguards, ensuring reliable operation. Ideal for photovoltaic inverter testing, electric vehicle power system validation, high-power component aging, and grid simulation, the EA-ELR 12000-20 3U combines precision, safety, and energy efficiency in a robust 3U chassis.

Key Features

• High Voltage and Power Capacity: Supports up to 2000V, 20A, and 15kW (9kW derated) for testing high-power DC sources and systems.
• Energy Recovery Function: Recovers up to 95.5% of consumed energy, feeding it back into the grid to lower operating costs and reduce heat dissipation.
• Wide Resistance Range: Offers adjustable resistance from 3.5Ω to 5300Ω, simulating various load conditions accurately.
• Comprehensive Protection: Includes overvoltage, overcurrent, and overpower protection mechanisms to prevent damage to the device and connected equipment.
• Multiple Operating Modes: Supports CV, CC, CP, and CR modes for flexible testing scenarios, including dynamic and static load simulations.
• Advanced Applications: Optimized for photovoltaic inverter testing, EV power system validation, grid simulation, and high-power component aging tests.
• User-Friendly Interface: Features a color TFT touchscreen, rotary knobs for easy adjustment, and USB/Ethernet interfaces for remote control and data logging.
• Master-Slave Parallel Operation: Allows up to 64 units to be connected in parallel for scalable power testing up to 960kW.
