EA-ELR 11000-40 3U Programmable Electronic DC Load with Energy Recovery

The EA-ELR 11000-40 3U is a high-performance programmable electronic DC load designed for energy recovery applications, capable of converting up to 95.5% of consumed DC energy back to the local grid; this 1000V, 40A, 15000W electronic load supports constant current (CC), constant voltage (CV), constant power (CP), and constant resistance (CR) operating modes, includes an integrated function generator for generating sine, triangle, rectangle, trapezoid, DIN 40839, arbitrary, ramp, and XY table waveforms, and offers advanced testing functions such as battery testing and MPP tracking for solar panel simulation; with its regenerative capability, it significantly reduces energy consumption and operating costs, while providing precise control and real-time monitoring via a 5-inch color TFT touchscreen, multiple communication interfaces (USB, Ethernet, analog, and optional digital modules), and support for master-slave parallel operation with up to 64 units for scalable power requirements.

Key Features

• High Power and Voltage Range: Handles DC inputs up to 1000V, 40A current, and 15000W power, with automatic derating to 9000W when operating on 208V AC supply.
• Energy Recovery System: Recuperates up to 95.5% of energy back to the grid, minimizing energy waste and heat dissipation.
• Multiple Operating Modes: Supports constant current (CC), constant voltage (CV), constant power (CP), and constant resistance (CR) for versatile load simulation.
• Built-in Function Generator: Generates various waveforms and sequences including sine, triangle, rectangle, trapezoid, DIN 40839, arbitrary, ramp, and XY table functions for dynamic testing.
• Advanced Testing Applications: Includes battery test function for discharge testing and MPP tracking for solar panel maximum power point simulation.
• User-Friendly Interface: Features a 5-inch color TFT touchscreen with capacitive touch, two rotary knobs with push-button function, and intuitive menu navigation for easy operation.
• Flexible Connectivity: Offers built-in USB, Ethernet, and isolated analog interfaces (15-pin D-sub), plus optional plug-in interface modules (e.g., CAN, Profibus, ModBus TCP, EtherCAT) for remote control and system integration.
• Scalable System: Supports parallel operation in master-slave mode with up to 64 units, allowing total system power up to 960kW.
• Comprehensive Protection: Includes adjustable overvoltage (OVP), overcurrent (OCP), overpower (OPP), overtemperature (OT), and power fail (PF) protections for safe and reliable operation.
• High Efficiency and Accuracy: Provides high efficiency up to 95.5% and accurate measurements with display accuracy of ≤0.05% FS for voltage and ≤0.1% FS for current.
