EA-ELR 10080-340 3U Programmable Electronic DC Load with Energy Recovery

The EA-ELR 10080-340 3U is a high-performance programmable electronic DC load from the ELR 10000 Series, designed for sophisticated DC load testing, power supply testing, battery testing, and solar panel testing applications. As an Electronic Load Recovery unit, it features advanced energy recuperation technology, feeding up to 94.5% of the absorbed DC energy back into the local grid with high efficiency. With a wide voltage range of 0-80V and a high current capability of 0-340A, it delivers a maximum power of 10,000W (15,000W for 3U models on 400V AC input, derated to 6,000W on 208V AC). It offers versatile operating modes including constant current (CC), constant voltage (CV), constant power (CP), and constant resistance (CR), and is equipped with a built-in function generator for creating complex test profiles like sine, triangle, rectangle, trapezoid, and arbitrary waveforms, as well as dedicated battery test and MPP tracking functions for photovoltaic panel simulation. The device supports master-slave parallel operation for scaling up to 960kW systems, and provides multiple remote control interfaces including USB, Ethernet, analog, and optional plug-in modules for CAN, Profibus, Profinet, ModBus TCP, and more, making it an ideal and energy-efficient solution for laboratory, industrial, and automotive component testing.

Key Features

• Energy Recovery System: Recuperates up to 94.5% of consumed DC energy and feeds it back into the AC grid, significantly reducing operating costs and heat dissipation.
• High Power & Current Density: Capable of 10,000W (15,000W for 3U) load power, with a high current range of 0-340A and voltage range of 0-80V, suitable for testing high-power sources and batteries.
• Versatile Operating Modes: Supports Constant Current (CC), Constant Voltage (CV), Constant Power (CP), and Constant Resistance (CR) modes for comprehensive source and component testing.
• Integrated Function Generator: Generates complex current or voltage profiles including sine, triangle, rectangle, trapezoid, arbitrary waveforms, and DIN 40839 automotive engine start simulation.
• Advanced Application Functions: Features dedicated Battery Test function for static/dynamic discharge and MPP Tracking function for solar panel characteristic curve simulation and evaluation.
• Master-Slave Parallel Operation: Enables seamless parallel connection of up to 64 units to create a single, high-power system up to 960kW with automatic current sharing and centralized control.
• Multiple Control & Interface Options: Offers front-panel manual control, remote control via built-in USB, Ethernet, analog interface, or optional plug-in modules (CAN, Profibus, Profinet, ModBus TCP, etc.).
• Comprehensive Protection & Monitoring: Includes Over Voltage Protection (OVP), Over Current Protection (OCP), Over Power Protection (OPP), Over Temperature (OT) protection, and user-definable event monitoring for safe and reliable operation.
• Data Logging & Connectivity: Front USB port for saving/loading sequences, user profiles, and recording measurement data (logging) in CSV format during operation.
