EA‑ELR 10750‑12 2U | 750V 12A 3000W Ultra‑High‑Voltage Energy‑Recuperating 19" 2U Rack‑Mount Programmable DC Electronic Load

The EA‑ELR 10750‑12 2U is part of EA‑ELR 10000 2U series manufactured by EA Elektro‑Automatik, distributed by TPS. It is a high‑power ultra‑high‑voltage regenerative DC electronic load as alternative to ametek/amtek test instruments. Well‑suited for dynamic‑profile load testing, high‑voltage power‑supply validation, high‑voltage battery discharge cycling, 24V DC source verification and PV module characterization, supporting remote‑sense and master‑slave parallel expansion.

Core Specifications: DC input range 0‑750V, 0‑12A, rated 3000W (derates to 1500W under 110‑127V AC mains), max energy‑recovery efficiency up to 95%. Minimum input voltage for full‑scale current:2.5V. CC‑mode rise / fall time ≤10 ms; measurement accuracy: voltage ≤0.05% FS, current ≤0.1% FS, power ≤0.3% FS. Supports CV / CC / CP / CR four regulation modes, resistance adjustment range:2 Ω‑3000 Ω. Wide‑range 100‑264V AC input, built‑in high‑voltage discharge circuit, multi‑function generator, battery‑test and MPP‑tracking function. 19‑inch 2U rack‑mount chassis with temperature‑controlled front‑to‑rear forced air cooling.

Key Features

• EA‑ELR 10750‑12 2U, 750V 12A 3000W regenerative programmable DC electronic load, PN:33200849
• 19‑inch 2U rack‑mount enclosure, dimension 482.6×88.4×559mm, weight approx.12.7kg
• Up to 95% energy recuperation, feeds absorbed DC power back to AC grid, reduces heat generation and long‑term operating expenses
• CV / CC / CP / CR four operating modes, constant‑resistance simulation for battery characteristic test scenarios
• 5‑inch capacitive TFT touch‑screen, dual push‑rotary knobs; front‑panel USB‑Host for CSV logging, waveform and user‑profile import‑export
• Integrated multi‑function generator: Sine, Triangle, Rectangle, Trapezoid, DIN40839, Arbitrary, Ramp, XY‑table; dedicated battery discharge test & MPPT solar panel simulation for dynamic‑profile load testing
• Built‑in high‑voltage discharge circuit, pulls residual DC voltage down below 60V within 10 seconds after DC‑input shutdown
• Comprehensive alarm protections: OVP, OCP, OPP, OT, Power‑Fail, Share‑Bus‑Fail with automatic DC‑input shutdown
• Remote‑sense terminals for DC cable IR‑drop compensation; galvanically‑isolated 15‑pin analog, rear USB & Ethernet onboard control interfaces
• Master‑Slave / Share‑Bus parallel operation support, connect up to 64 identical‑series units for scalable high‑power combined test system
• SCPI / ModBus RTU protocol compliant, EA Power Control software and LabView driver available; optional IF‑AB plug‑in modules: CANopen, ProfiNet, EtherCAT, RS232, ModBus‑TCP etc.
• Complies with EN 61010‑1 safety standard, IP20 ingress protection for laboratory and industrial test environments
