EA‑ELR 10360‑30 2U | 360V 30A 3000W Energy‑Recuperating 19" 2U Rack‑Mount Programmable DC Electronic Load

The EA‑ELR 10360‑30 2U is part of EA‑ELR 10000 2U series manufactured by EA Elektro‑Automatik, distributed by TPS. It is a high‑power regenerative DC electronic load as alternative to ametek/amtek test instruments. Ideal for high‑voltage power supply validation, high‑power battery discharge testing, 24V DC source verification, PV module evaluation and industrial ATE test systems supporting parallel expansion.

Core Specifications: DC input range 0‑360V, 0‑30A, rated 3000W (derates to 1500W under 110‑127V AC mains), maximum energy‑recovery efficiency up to 94.5%. Minimum input voltage for full‑scale current:2V. CC‑mode rise / fall time ≤10 ms; measurement accuracy: voltage ≤0.05% FS, current ≤0.1% FS, power ≤0.3% FS. Supports CV / CC / CP / CR four regulation modes, resistance adjustment range:0.4 Ω‑800 Ω. Wide‑range 100‑264V AC input, built‑in multi‑function generator, battery‑test and MPP‑tracking function. Compact 19‑inch 2U rack‑mount chassis with front‑to‑rear temperature‑controlled forced air cooling.

Key Features

• EA‑ELR 10360‑30 2U, 360V 30A 3000W regenerative programmable DC electronic load, PN:33200847
• 19‑inch 2U rack‑mount enclosure, dimension 482.6×88.4×559mm, weight approx.12.7kg
• High‑efficiency energy recuperation feeds absorbed DC power back to AC grid, reduces heat dissipation and long‑term operating expenses
• CV / CC / CP / CR four operating modes, constant‑resistance simulation for battery characteristic test scenarios
• 5‑inch capacitive TFT touch‑screen, dual push‑rotary knobs; front‑panel USB‑Host for CSV logging, waveform and user‑profile import‑export
• Integrated multi‑function generator: Sine, Triangle, Rectangle, Trapezoid, DIN40839, Arbitrary, Ramp, XY‑table; dedicated battery discharge test & MPPT solar panel simulation
• Comprehensive alarm protections: OVP, OCP, OPP, OT, Power‑Fail, Share‑Bus‑Fail with automatic DC‑input shutdown
• Remote‑sense terminals for DC cable IR‑drop compensation; galvanically‑isolated 15‑pin analog, rear USB & Ethernet onboard control interfaces
• Master‑Slave / Share‑Bus parallel operation support, connect up to 64 identical‑series units for high‑power combined test system
• SCPI / ModBus RTU protocol compliant, EA Power Control software and LabView driver available; optional IF‑AB plug‑in modules: CANopen, ProfiNet, EtherCAT, RS232, ModBus‑TCP etc.
• Complies with EN 61010‑1 safety standard, IP20 ingress protection for laboratory and industrial test environments
