EA-EL 9750-05 DT 400W Programmable Electronic DC Load

The EA-EL 9750-05 DT is a 400W benchtop DC electronic load from the EA-EL 9000 DT series, designed for precise testing of power supplies, batteries, and solar inverters. It supports four regulation modes: constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR). With a wide input voltage range of 0–750V and a maximum current of 5A, it is ideal for high-voltage, low-current applications in labs, schools, and workshops.

Equipped with an intuitive multilingual color touch panel, a built-in true function generator, and multiple remote control interfaces, it offers both ease of use and advanced programmability. The device also features comprehensive protection functions including OVP, OCP, OPP, and thermal derating to ensure safe operation.

Key Features

• Four Operation Modes: CV, CC, CP, and CR for flexible testing scenarios.
• High Voltage Range: 0–750V DC input with 5A maximum current.
• Power Rating: 400W at 25°C with thermal derating at higher temperatures.
• True Function Generator: Generates sine, rectangle, triangle, and arbitrary waveforms for dynamic load testing.
• Battery Test Mode: Measures elapsed time, capacity (Ah), and energy (Wh) for battery discharge testing.
• MPP Tracking: Simulates solar inverter characteristics for photovoltaic system testing.
• Color Touch Panel: Multilingual interface (German, English, Russian, Chinese) for intuitive operation.
• Remote Control: USB, Ethernet, and analog interfaces with SCPI and ModBus RTU support.
• Wide AC Input: 90–264V AC with active PFC for global use.
• Protections: Adjustable OVP, OCP, OPP, and thermal derating for safe operation.
