EA-EL 9360-10 DT 450W Programmable Electronic DC Load

The EA-EL 9360-10 DT is a high-precision, programmable electronic DC load designed for laboratory, workshop, and educational applications. As part of the EA-EL 9000 DT series, it offers a compact desktop form factor with a power rating of 450W at 40°C (600W at 25°C), covering a voltage range of 0–360V and a current range of 0–10A. It supports four regulation modes: constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR). Equipped with a multilingual color TFT touch panel, an integrated true function generator (sine, rectangle, triangle, and arbitrary waveforms), and galvanically isolated interfaces (USB, Ethernet, analog), it ensures safe and flexible operation both locally and remotely. The device also features advanced battery testing with Ah/Wh counting, MPP tracking for photovoltaic simulations, and programmable protections (OVP, OCP, OPP), making it ideal for testing power supplies, batteries, solar inverters, and other DC sources.

Key Features

• Wide Input Range: 0–360V, 0–10A, 450W (600W peak at 25°C)
• Four Regulation Modes: CV, CC, CP, CR
• Integrated True Function Generator with arbitrary waveform support
• Color TFT Touch Panel with multilingual interface (DE, EN, RU, CN)
• Battery Test Mode with capacity (Ah) and energy (Wh) measurement
• MPP Tracking for photovoltaic and solar inverter testing
• Galvanically Isolated Interfaces: USB, Ethernet, Analog
• Programmable Protections: OVP, OCP, OPP
• Supports Remote Control via SCPI, ModBus RTU, and LabView VIs
• Thermal Derating for safe operation up to 50°C
