Product Description
EA‑PSI 9750‑04 DT | 750V 4A 1000W Ultra High Voltage Auto-Ranging Programmable Desktop DC Power Supply
The EA‑PSI 9750‑04 DT belongs to German EA Elektro‑Automatik PSI9000 DT series, distributed by TPS, premium ultra-high voltage bench DC source as alternative to ametek programmable power supply for high-voltage component testing, PV/solar panel simulation, capacitor & new energy product verification and automated industrial test system.
Core Specs: 0~750V / 0~4A continuously adjustable, rated 1000W max output power, peak efficiency up to 93%, output ripple 94mV PP/16mV RMS, current ripple 10mA RMS. Universal 90~264V full-range AC input with active PFC; HV ≥200V built-in safety discharge circuit drains residual voltage below 60V within 10s after output shutdown.
Key Features
- EA‑PSI 9750‑04 DT, 750V 4A 1000W ultra-high voltage programmable desktop supply, PN:06200510
- Chassis dimension:308×103×415mm, approx.8.2kg with foldable tilt stand & portable carry handle
- Active PFC(PF＞0.99), auto-ranging CV/CC/CP/CR four control modes with built-in internal resistance simulation
- Full-featured waveform generator: Sine/Triangle/Rect/Ramp/DIN40839/Arbitrary custom curve for PV characteristic simulation
- Full OVP/OCP/OPP/OTP multi-layer safety protection + front remote sensing for cable IR drop compensation
- Galvanic isolated 15Pin Analog + USB-A/USB-B + Ethernet standard onboard communication ports
- SCPI & ModBus RTU compliant, compatible with EA Power Control & LabView driver for automatic test equipment integration
- Front USB for saving/loading user test profiles & arbitrary high-voltage simulation sequences
Specifications
| Parameter | Value |
|---|---|
| Output Current | 0-4A |
| Output Power | 1000W |
| Output Voltage | 0-750V |
| Characteristic Curve | U/I/P autoranging |
| External Control | Analogue 0-5V/0-10V, USB, LAN, Modbus TCP |
| Housing | Desktop (table) |
| Human Interface | Touch panel & Menu |
| Special Feature | Function Generator, Resistance |
Technical data sheets
Legislation and Compliance
-
RoHS
-
CE
-
UL
-
WEEE
-
UKCA
