Product Description
EA‑EL 9360‑20 DT | 360V 20A 900W Programmable DC Electronic Load
The EA‑EL 9360‑20 DT is a high‑performance bench‑top electronic load from EA Elektro‑Automatik, distributed by TPS. As part of the EL 9000 DT Series, it serves as a versatile alternative to ametek/amtek loads, ideal for testing 24v power supplies, DC power supplies, and programmable bench power supplies.
Key specs: EA‑EL 9360‑20 DT, 360V max voltage, 20A max current, 900W steady power. Features 4.3‑inch color TFT touchscreen, true function generator, and OVP/OCP/OPP protection. Standard galvanic isolated USB/Ethernet/analog interfaces enable seamless remote control for lab, R&D, and industrial testing.
Key Features
- EA‑EL 9360‑20 DT, 360V 20A 900W DC electronic load
- 4 regulation modes: CV/CC/CP/CR electronic load
- True function generator, color TFT touchscreen
- OVP/OCP/OPP protection, USB/Ethernet/analog interfaces
- Compact bench‑top, tilt stand, 2U rack‑mountable
- For 24v/DC/bench programmable power supply testing
Specifications
| Parameter | Value |
|---|---|
| Output Current | 0-20A |
| Output Power | 900W |
| Output Voltage | 0-360V |
| Type | 3U |
| Characteristic Curve | U/I/P autoranging |
| External Control | Analogue 0-5V/0-10V, USB, LAN, Modbus |
| Housing | 19" rack |
| Human Interface | Touch panel & Menu |
| Special Feature | Function Generator, Resistance |
Technical data sheets
Legislation and Compliance
-
RoHS
-
CE
-
UL
-
WEEE
-
UKCA
