Product Description
EA‑PS 3200‑02 C | 200V 2A 160W Programmable Desktop DC Power Supply
The EA‑PS 3200‑02 C is a compact, high‑precision programmable desktop DC power supply from EA Elektro‑Automatik, distributed by TPS. As part of the EA‑PS 3000 C Series, it’s a reliable alternative to ametek/amtek power supplies, ideal for lab research, education, and testing 24v power supplies, DC power supplies, and programmable bench power supplies.
Key specs: EA‑PS 3200‑02 C, 160W lab power supply, 0‑200V programmable power supply, 0‑2A programmable power supply. Features active PFC with 90‑264V wide AC input, auto‑ranging output stage, and full protection (OVP/OCP/OPP/OTP). Equipped with a 4.3‑inch color TFT touchscreen, remote sensing, and optional galvanic isolated USB/Ethernet/analog interfaces.
Key Features
- EA‑PS 3200‑02 C, 200V 2A 160W DC power supply
- EA‑PS 3000 C programmable desktop DC power supply
- 200V programmable power supply, 2A programmable power supply
- 160W lab power supply, auto‑ranging power supply
- Active PFC, 90‑264V wide AC input
- OVP/OCP/OPP/OTP full protection, remote sensing
- 4.3‑inch color TFT touchscreen, multi‑language HMI
- Optional USB/Ethernet/analog interfaces, SCPI/ModBus supported
- Compact desktop design, tilt stand, easy operation
- For ametek‑grade bench/DC/programmable power supply testing
Specifications
| Parameter | Value |
|---|---|
| Output Current | 0-2A |
| Output Power | 0-160W |
| Output Voltage | 0-200V |
| Characteristic Curve | U/I flexiranging |
| External Control | USB |
| Housing | Desktop (table) |
| Human Interface | Simple manual controls |
Technical data sheets
Legislation and Compliance
-
RoHS
-
CE
-
UL
-
WEEE
-
UKCA
