EA-EL 9500-16 DT 600W Programmable DC Electronic Load

The EA-EL 9500-16 DT is a 600W benchtop programmable DC electronic load designed for laboratory, workshop, and educational use. It is part of the EA-EL 9000 DT series and supports four regulation modes: constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR). With an input range of 0–500V and 0–16A, this model is ideal for testing power supplies, batteries, and photovoltaic systems. It features a color TFT touch panel for intuitive operation, a built-in true function generator for waveform simulation, and galvanically isolated interfaces (USB, Ethernet, analog) for safe remote control. The unit also includes battery test mode with Ah/Wh counting and MPP tracking for solar inverter characterization, making it a versatile tool for both R&D and production testing.

Key Features

• Wide Input Range: 0–500V, 0–16A, 0–600W at 25°C.
• Four Operation Modes: CV, CC, CP, CR for flexible testing scenarios.
• Touch Panel Interface: Multilingual color TFT display with intuitive controls.
• Built-In Function Generator: Supports sine, rectangle, triangle, and arbitrary waveforms.
• Battery Test Mode: Logs time, capacity (Ah), and energy (Wh) with adjustable stop conditions.
• MPP Tracking: Simulates solar inverter behavior for photovoltaic testing.
• Isolated Communication Ports: USB, Ethernet, and analog interface for safe remote control.
• Programmable Protections: OVP, OCP, OPP, and OTP for device and DUT safety.
• Thermal Derating: Automatically adjusts power based on ambient temperature.
• Software Support: Includes EA Power Control for Windows and LabVIEW VIs.
