EA-EL 9360-20 DT 900W Programmable Electronic DC Load

The EA-EL 9360-20 DT is a high-performance, benchtop programmable DC electronic load from the EA-EL 9000 DT series, designed for versatile testing applications in laboratories, schools, and workshops. It supports 0...900 W power (0...800 W at 40°C), 0...360 V DC input voltage, 0...20 A current, and 1.6...540 Ω resistance range, making it ideal for testing 24V power supplies, DC power supplies, battery packs, and photovoltaic systems. Featuring a multilingual color TFT touch panel (German, English, Russian, Chinese), it offers intuitive operation and real-time monitoring of set and actual values. The device includes four regulation modes—constant voltage (CV), constant current (CC), constant power (CP), and constant resistance (CR)—along with a built-in true function generator capable of generating sine, rectangle, triangle, and arbitrary waveforms for dynamic testing. Advanced functions like battery testing (with Ah/Wh counting) and MPP tracking for solar panel simulation enhance its utility in R&D and production environments. Remote control is facilitated via galvanically isolated USB, Ethernet, and analog interfaces, with support for SCPI, ModBus RTU, and ready-to-use LabView components. The unit also features adjustable OVP, OCP, OPP protections, thermal derating, and a front USB port for saving/loading test sequences.

Key Features

• Wide Power & Voltage Range: 0...900 W (800 W @ 40°C), 0...360 V DC, 0...20 A, 1.6...540 Ω resistance.
• Four Regulation Modes: CV, CC, CP, CR for flexible load simulation.
• True Function Generator: Sine, rectangle, triangle, and arbitrary waveforms applicable to voltage or current.
• Battery Test & MPP Tracking: Discharge testing with Ah/Wh measurement; MPP simulation for PV testing.
• Intuitive Touch Interface: Multilingual TFT color touch panel with user profiles.
• Comprehensive Connectivity: Galvanically isolated USB, Ethernet, analog ports; SCPI, ModBus RTU, LabView support.
• Robust Protections: Adjustable OVP, OCP, OPP; thermal derating; temperature-controlled cooling.
• Portable & Compact: Desktop design with carrying handle and tilt stand.
